Description
| Interface Type | 1 × 10/100/1000/2500 Mbps RJ45 PoE IN 1 × 10/100/1000/2500 Mbps RJ45 cable Data OUT 1 × DC 2.0 power cable (Max: 12V / 2.1A) |
| PoE / PD Standard | IEEE 802.3af/at Class 4 (Max: 25W) |
| PoE IN | PIN: 1236+, 4578- |
| DC OUT | 1 × DC 2.0 power output cable (Max: 12V / 2.1A or 24V / 1A) |
| Network Protocol | IEEE 802.3 10BASE-T IEEE 802.3i 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3x IEEE 802.3ab 1000Base-T IEEE 802.3bz 2.5GBase-T |
| Transmission Medium | 10BASE-T : Cat3, 4, 5 or higher grade TP cable 100BASE-TX / 1000Base-T : Cat5, 5e, 6 or higher grade TP cable 2.5GBase-T : Cat5e, 6 or higher grade TP cable |
| Operating Temperature | -40 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Relative Humidity | 5% ~ 95% (non-condensing) |
| Thermal Methods | Fanless design, natural heat dissipation |
| MTBF | 100,000 h |
| Protection Grade | IP40 |
| EMC | Power Surge: IEC 61000-4-5 4KV / 2KV (8/20 μs) Network port Surge: IEC 61000-4-5 4KV / 2KV (10/700 μs) ESD: IEC 61000-4-2 8KV / 15KV |
| Product Size | Cable length: 30 cm Metal case: 72 × 32 × 32 mm |
| Package Size | / |
| Installation Method | Desktop |
| Weight | 0.11 kg |
| Package Info | / |
| Warranty | 1 Year |
